'Functional load example case' simulation project by ahmedhussain18

[ahmedhussain18]

Formula used for static load at certain point:

F (x,y,t) = (F * exp(-2((x-x_o)+(y-y_o))/r²)/πr²

Formula used for moving load at certain point along x-axis:

F (x,y,t) = (F * exp(-2((x-(x_o* t))+(y-y_o))/r²)/πr²

Where,

F = applied force value in Newton
r = radius of the circular region in meters where force is applied with center (x_o,y_o)
x_o= x coordinate value of load center point in meters
y_o= y coordinate value of load center point in meters
t = simulation time
