Rotor and shaft connection analysis. 4 step simulation:
1. Interference fit
2. Centrifugal load
3. Torque
4. Temperature increase - Copy - Copy

Cover is offset by 0.005 meter, 2 snaps,
Assumptions : Symmetric on both planes.
Only a quarter portion of enclosure is analysed.

Heat transfer analysis of a near net ring forging being quenched in water and in molten salt.

A centrifugal pump with AI result prediction.

Hydrofoil Product Demo.
Highlights:
1. Lift and Drag coefficients of a Hydrofoil
2. Wall shear Stress analysis
3. Surface and Stagnation Pressure

Natural convection analysis of a Street light assemlbly with 3 LED modules of 12 LEDs each.

Example project of a multiphysics application. A Static and a Frequency analyses are used to determine the structural behavior of the assembly. Then, a conjugate heat transfer analysis will determine the thermal behavior of the cooling process of the motor.

The purpose of this project is to analyze the thermal performance of this hydronic heat exchanger

Structural simulation according to UN 38.3 T3 vibration test criteria

LED Spotlight project, aiming to bring the temperature of the diodes of an LED spotlight design below the maximum allowed temperature of the diodes of 90C. Comparison of different heat sink designs

Robotic gripper FEA stress simulation, copy of https://www.simscale.com/projects/rviswanathan/gripper/

Checking the sealing fitting process on a quarter symmetry model with and without friction. This is a sample hyperelastic rubber material using the Mooney-Rivlin model. Results of interest are the required fitting force as well as the contact state and pressure.

Demo of cooling of Raspberry Pi using the Immersed Boundary Method (IBM).
IBM makes CAD cleanup and defeaturing obsolete. A CAD with detailed electronic features (pins, connectors, engravings, etc.) can be directly imported as is for simulation
In this demo a Raspberry Pi is overclocked and the heat transfer behaviour is compared for two cases where the fan is off and on.

Thermomechanical analysis of a cast iron exhaust manifold

This project focus on the stress analysis of two different models of cardiovascular stent using two different materials - 316 LN Stainless Steel and L605 Co-Cr.

See how to setup and run a low speed drop test dynamic analysis of a plastic bottle being dropped from 1m height.

Apply elasto-plastic properties to the bottle material using a bilinear model with perfect plasticity.

Setup and run a dynamic analysis of an acceleration signal applied on a bottle during transportation.

In this quick demo, the large mass method is used, to apply the acceleration signal via a force boundary condition.

Checking stresses and deformation on two different bottle crates for different loading conditions

Evaluate the performance of 3 different axial fan designs and seamlessy extract fan efficiency curves.

Quickly perform RPM sweeps to evaluate the axial fan model under different operating conditions

Cooling plate design of a hydrogen fuel cell

CFD analysis of a Vertical Farming tower system to understand and optimize the following:
1. Flow characteristics based on different supply flow rates (0.2, 0.3, 0.4, 0.5 kg/s)
2. Optimize the humidity level over the plant trays
3. Determine the optimal inlet / Outlet configuration

In this project a static linear structural analysis of a wheel loader arm is demonstrated.

Engineering study of solar panels, including:

1. Wind loading and static structural analysis of a single panel

2. Transient wind analysis of a panel array - Copy

A Pedestrian Wind Comfort of a proposed site in Boston, USA.

Evaluate the influence of a cement column in a 3D thermal bridge

This project demonstrates the validity of the CHTv2 and IBM solver. through a Conjugate Heat Transfer (CHT) analysis of a battery pack.

Validation Experiment Reference:
A peer-reviewed publication on battery pack thermal validation  has been used as basis for this study (with reasonable assumptions and approximations):
https://www.mdpi.com/1996-1073/10/8/1157

Steady state and transient analysis of an industrial 7 blade fan ducted fan assembly with cowling.

This study aims at validating the CHT v2 solver of SimScale GmbH with IBM as an option. A peer-reviewed publication focussing on thermal analyses and cooling of an RF electronics package has been used as the basis for this validation case.

A simulation of a battery pack cooling case that is controlled through the SimScale API by Valispace configuration management for an electric vehicle.

Nonlinear static FEA on a typical automotive bodywork push pin rivet.  Assess survivability vs. manufacturability vs. weight of part.

This tutorial project aims to showcase how to set up and run a simulation for a pump geometry. The Standard meshing tool was used.

In this project, a thermal shock & flow analysis of a globe valve is performed. Multiphase (Air/Water) & Single phase flow is modeled.

Example battery pack vibration project demonstrating Solidworks Plugin with CAD Associativity. The models in Solidworks can be exported to SimScale with just a few clicks within the Solidworks interface.

Transient analysis of external aerodynamics of a quadcopter drone with conventional propellers and with toroidal propellers. Featured by The Action Lab in this video: https://youtu.be/z58RORCUTao

Fan forced convection cooling of an EV battery pack

Quadcopter Drone  used for drone zone webinar

Industrial mixing tank example using the Multiphase solver.

In this example, a simple tank and a baffled tank design are compared in terms of mixing performance. The simulation involves 2-phases (air/water) and rotating parts (impellers).

As a final step, a sparger is implemented at the bottom of the tank, to simulate the tank aeration process.

This example is part of our free on-demand Multiphase webinar. Please register via the following link to watch how this case was setup inside the SimScale platform.
https://www.simscale.com/webinars-workshops/new-multiphase-flow-capabilities/

This project simulates a solid-state relay under a 15W heat load.
This relay includes a heat sink that acts as a fixture from the relay housing to the mounting wall. The product is tested under natural convection conditions at 20C.

Credits to Xinchao Song for the 3D model used in this project.  Link : https://tinyurl.com/ycd6cvug

Shelf loading example

The aim is to design a shelf that can withstand certain amount of load.

Failure in this case can be assessed  by either:
(1.) Assessing the maximum stresses developed on the plastic shelf versus different loading conditions
(2.) Checking whether shelf bending might lead large deformations such that the shelf might fall off the mounts

Assessment of the water level of a cooling tower water distribution open channel.

The channel has a water inlet and numerous holes for outlet, while it is open to the atmosphere.

Three different designs are evaluated to optimize the filling performance. Watch our on-demand webinar about Multiphase capabilities where this case is presented in more detail
https://www.simscale.com/webinars-workshops/new-multiphase-flow-capabilities/
