This project contains everything you need to work on the first homework assignment of the drone workshop

Tutorial project for a stress analysis of a connecting rod. The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.

Apipe with a diameter of0.5 cmand the radius of curvature of0.5 cm.  The straight portion of pipe before the bendis 2.6 cmand the straight portion after the bendis 4.6 cm.  Air entering the pipe with a mean velocity of4.7 m/sand at a temperature 25 oC whilethe pipe exit pressure is 0 atm.Heating is provided with 119 W/m2 on the surface of the entire length of the pipe.Case 2 (Mod3b.stp)Same flowinvolves an equivalent length of8cm long pipe with the same diameter of 0.5 cm.Fluid properties for air at 2

Case 1 (Mod3a.stp)Apipe with a diameter of0.5 cmand the radius of curvature of0.5 cm.  The straight portion of pipe before the bendis 2.6 cmand the straight portion after the bendis 4.6 cm.  Air entering the pipe with a mean velocity of4.7 m/sand at a temperature 25 oC whilethe pipe exit pressure is 0 atm.Heating is provided with 119 W m2 on the surface of the entire length of the pipe.
