DIscover the input and output affect of water

This project is for school and were going to use the fluid simulation for pressure. the goal of this project is to create a device which involves pressure and temperature

Analysis of PTFE seated double offset buttefly valve design (150 class) In order to evaluate the Cv and pressure drop through valve.

FEA- Offshore reel hose- case 1 testing Tension, Torsional & Bending Load

Pipes in Oil and Gas Industries are widely exposed to higher temperatures and pressures which might lead to blowouts. In order to prevent pipe breakage due to blowouts, closing and sealing of pipes is of high necessity. For this, the pipes are Simulated for Nonlinear case with larger deflections and contacts using two flat stiff indentors.

Pipe safety assessment against thermal load.

Two different designs of a pipe junction are analyzed regarding their downstream behavior.

Flow in sudden expansion from 10 mm to 30 mm. To determine the loss coefficient and compare with equations in standard literature
