This project shows analysis of the Heat transfer Process in a heat sink.

Project for setting up a Multi-phase flow simulation

The tutorial project is a sample Electronic cooling sink which consists of 3 solid regions and 1 fluid region. The solid regions are two FB-4 chips, which have a higher initial temperature and a heat sink over one of the chips. The air flows over the solid regions to remove the heat from it.

Tutorial for In-compressible Turbulent flow through a cyclone seperator

Tutorial project for a flow analysis of a pipe junction. The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.

Tutorial project for a thermal analysis of a differential casing. The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.

Forced Convective Heat Transfer - Raspberry Pi
