rules1
1350*250 main s1210 5deg
150*200 side 30deg
200*275 ,middle 20deg

8 deg + 6 deg (manual mesh & auto solve )

In this tutorial, a aerodynamic analysis of a F1 frontwing is presented. The flow around the wing is modeled as an incompressible, turbulent flow using a k-epsilon turbulence model. This tutorial is based on the first part of the SimScale F1 Simulation workshop series about aerodynamics.
