This test is to determine the effect of active air cooling on a motor

heat exchanger to simulate the convection transfer of heat from the walls

exchange of heat assuming the walls take the temperature of a fluid and air is allowed to pass over it

Tutorial project for Aerodynamic simulation of compressible flow over Airfoil

In this tutorial, a aerodynamic analysis of a F1 frontwing is presented. The flow around the wing is modeled as an incompressible, turbulent flow using a k-epsilon turbulence model. This tutorial is based on the first part of the SimScale F1 Simulation workshop series about aerodynamics.

This project shows an electronic cooling application of ICs on PCB using the conjugate heat transfer transfer technique, abbreviated as CHT. Conjugate heat transfer defines processes which involve variations of temperature within solids and fluids due to thermal interaction.

Tutorial for In-compressible Turbulent flow through a cyclone seperator

This  project analyzes the aerodynamics of a spoiler

This tutorial shows how to analyze the Heat transfer in a heat sink.

Tutorial project for a flow analysis of a pipe junction. The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.

Tutorial project for setting up a Multi-phase flow simulation
