This project is testing my design of an airplane, aswell as testing the different tail configurations to choose which one I should use.

This will cover research study of the SU-57 Flight Dynamics:

Drag,
Lift,
Stalls

A test of a glider to see the fluid dynamics

This project involves meshing externally a Boeing 777-200 LR Aircraft, and then simulating its' operation on flight facing an airflow with an axial velocity of 50 m/s.  It is one of the longest-range commercial airliners, with an exterior length and wingspan reaching 63.70 and 64.80 meters respectively.  For this case a model with removed engines was chosen in order to assist convergence and meshing. Also a Symmetry plane was added midst the Part, and half the part was used for meshing and simulation for simplification.  A steady state compressible flow simulation is executed to visualize the air flow around the bodywork and wings of the aircraft, as well as the pressure distribution while on flight.

This project important point of video shooting and very impressive photos click by drones camera

Just a side project to see whether an idea could work. On paper, this works, but I would also like to see whether the simulation of this also works to give me enough confidence to build it.
