A 3D printer fan duct, simulated thanks to SimScale.

Thermal analysis of cooling system for solar panels

How air circulating around the room by using two ACs on strategic position

settinh the temperature, the water in evaporate place

Inspired by this article https://insideevs.com/news/339220/tesla-model-3-battery-can-transfer-twice-the-heat-of-model-s-p100d/  this project goal is to evaluate the difference in cooling effectiveness between series and parallel cooling tube of an EV Battery Module.

The cooling strategies used to maintain the battery under 40C are cooling tubes places between the rows of cells. Inside the aluminium channel extrusions flows a coolant made of water and glycol.

Hotend cooling system for Micro Swiss direct drive extruder for Creality CR-10 / Ender 3 printers.

ender 5 pro partcoling for fanduct  with two fans

This project goal is to determine  the narrowest ribbon that would provide enough cooling to the battery cells

To impart cooling to the electronic components

Jominy end quench test for steel. Hardenability

Goal is to make fan to cool electric motor while working with increased power
Aero simulation

find the heat flow inside an insulated container

Ender-5 Pro low noise cooling air duct for the motherboard.

Measuring the electric heat flow through the copper plates for the Carbon-PAEK sample

we are going to cool our engine with the fins.

Powertrain for hypothetical electric vehicle for cooling

this project is to test differnet cooling plate simulations

Verify the steady state temperature of the heat break  to avoid heat creep which causes filament expansion and jam.

Room air flow with 1 window opening and a sliding window panel

The goal of this project is to simulate the simplified version of the cooling system of the HP Workstation Notebook.
This is a Conjugate Heat Transfer (CHT) problem. Incompressible turbulent flow was assigned for the air flow. Two cooling scenarios are going to be investigated
1- Current cooling system
2- External cooling fan assisted system
