testing venturi tube with angles from wikipedia

od:24 //outlet diameter id:19 //inlet diameter td:12 //throat diameter oh:24 //outlet height ih:19 //inlet height th:10 //throat height oa:45 //outlet angle na:30 //nozzle angle

od:24 //outlet diameter
id:19 //inlet diameter
td:12 //throat diameter
oh:24 //outlet height
ih:19 //inlet height
th:10 //throat height
oa:45 //outlet angle
na:20 //nozzle angle

Accurately calculate pressure drop across venturi nozzle

Tutorial project for a flow analysis of a pipe junction. The project only provides the geometry to start with. See our tutorials section to have a look at the step-by-step instructions to set up the simulation.
