Regardless of the industries they are specialized in, engineering offices from all over the world are using the SimScale simulation platform to virtually test their design via a standard Web browser and deliver the best quality to their customers in less time. | Page 203

weldhead holder static and impact simulation

Araldite 2-component epoxy bond strength Analysis
Components in assembly:
1. Pipe (16 bar max) PVC
2. Turbidity sensor cup PP 20mm diameter
3. Adhesive Lining (Araldite 420 A/B epoxy)

TEST PLAN:
Failure Mode Effect Analysis (FMEA) (Abnormal condition setting)

 1. Tension on araldite adhesive
     layer (0.1mm thick)
 2. Pressure on turbidity sensor Polypropylene (PP) cup (4 bar)
 3. PVC pipe fixed support at lower
     end. Gravity not applied
     (Inconsequential here)


Theoretical information on Araldite material used:
Lap shear strength after various cure times at 23-degree Celsius (for 0.10mm thickness)
 5 hours: 1 N/mm²
 6 hours: 8 N/mm²
7 hours: 9 N/mm²

(Source URL: https://www.spacematdb.com/spacemat/manudatasheets/araldite-420-tds-v1.pdf)

The final result shows a maximum stress of 11 N/mm² (11MPa) on the PP turbidity sensor cup. Even less on the adhesive bond layer.

Mi proyecto se trata sobre como las estructuras pueden aguantar terremotos

Dropping Concrete through an orifice down a long shaft
